Large-Scale EO Sterilizer

• Large processing capacity, suitable for industrial needs: With a chamber volume of up to 10,000L, it can process thousands of medical consumables (such as 100,000 surgical masks) or batches of electronic components in a single run. This delivers processing efficiency 10-100 times that of smaller devices, matching manufacturers' mass production schedules and significantly reducing unit sterilization costs.
• Low-temperature sterilization, seamless product protection: Sterilization temperatures are controlled at 30-60°C, significantly lower than steam sterilization (121°C) and dry heat sterilization (above 160°C). This ensures the structural integrity and performance stability of heat-sensitive items such as plastics, rubber, electronic components, and biological products, preventing material deformation and functional failure caused by high temperatures. Broad spectrum and high efficiency, eliminating sterilization blind spots: EO gas has excellent permeability, penetrating deep into internal crevices (such as joints in surgical instruments and between pins of electronic components), effectively killing virtually all types of microorganisms with a sterilization pass rate of 99.9999% (meeting medical "sterile grade" standards), completely eliminating the problem of "sterilization blind spots."
• Fully automatic control and strong compliance: The fully automatic PLC control system, coupled with touchscreen operation, allows preset sterilization programs for specific applications such as "medical consumables" and "electronic components." It also monitors parameters such as temperature, humidity, and EO concentration in real time, and stores ≥1 year of sterilization data, meeting GMP, FDA, and QS compliance requirements for the medical industry and the food industry, facilitating quality traceability and auditing.
• Safe and environmentally friendly: Equipped with an EO leak detection sensor (operating environment leakage concentration ≤ 0.5ppm), an Ex d IIB T4 Ga explosion-proof chamber, and either a catalytic combustion (≥99.9% efficiency) or chemical absorption exhaust gas treatment system, ensuring operator safety while preventing EO exhaust gas from polluting the environment.

How the Product Works

1. Pretreatment Phase: Items to be sterilized are placed in the chamber. After closing the chamber, vacuum is first applied to remove air. The chamber temperature is then adjusted to 30-60°C and the humidity to 40%-80% in preparation for sterilization.

2. Sterilization Phase: EO gas at a concentration of 400-1200 mg/L is injected into the chamber and maintained at the set temperature and humidity for 1-6 hours. EO sterilizes microbial proteins and nucleic acids by destroying them.

3. Desorption Phase: Residual EO in the chamber is removed. Vacuum extraction and air exchange or thermal desorption is used to remove EO residues adsorbed on the items. Desorption typically takes 6-24 hours.

4. Post-treatment Phase: Items are tested for EO residue and removed. Exhaust EO gas is then decontaminated to prevent environmental contamination.

Why choose us?



As an innovative ethylene oxide (EO) sterilizer specialist, Riches boasts a core team of seasoned, qualified engineers with extensive pharmaceutical industry experience. Their in-depth mastery of EO sterilization processes allows precise resolution of various technical challenges in sterilization.

In service, Riches leverages strong project management and proven turnkey engineering expertise to deliver one-stop solutions covering the entire sterilization process. From customized solutions, equipment configuration and process execution to post-process testing, it provides full-process control-greatly cutting enterprise collaboration and communication costs while ensuring efficient sterilization.

For compliance, Riches strictly follows CE standards and aligns with international benchmarks like EN1422 and ISO11135. This guarantees the safety and standardization of sterilization processes and results, meeting the compliance requirements of customers across diverse global regions.



FAQ

What is the core difference between Large-Scale EO Sterilizer and small EO sterilizers?

The key differences lie in processing scale and application scenarios: Large devices have a chamber volume of 500-10,000L and can process thousands of items at a time, meeting the batch sterilization needs of manufacturers. Small devices, with a chamber volume of less than 100L, are primarily used for sterilizing small batches of consumables in hospitals. Furthermore, large devices are typically equipped with more complex fully automated control systems and exhaust gas treatment systems to meet industrial compliance requirements.

What industry standards must Large-Scale EO Sterilizer meet before they can be put into use?​
Compliance with both national and international standards is required: Chinese standards include GB 15599-2018 "Safety Requirements for Ethylene Oxide Sterilizers" and GB 18279.1-2015 "Sterilization of Healthcare Products - Ethylene Oxide"; international standards include ISO 11135-1:2014 (Sterilization of Medical Devices) and FDA 21 CFR Part 820 (Quality Management of Medical Devices). Different application areas (such as food packaging) also require compliance with specific industry safety standards.
